Ê Remove the DynamicLoM module (2).
Ê If no new DynamicLoM module will be installed,
Ê Remove the three bolts (see figure 114).
Ê Fasten the system board screw (see figure 113).
9.4.2.3 Installing the dummy cover
Figure 119: Installing the dummy cover
Ê Insert the dummy cover. Notice the position of the handle.
9.4.2.4 Concluding steps
Ê Install riser module 2 and riser module 3 as described in section "Installing
a riser module" on page 63.
Ê "Reassembling" on page 54
Ê "Connecting the server to the mains" on page 60
Ê "Switching on the server" on page 61
Ê "Enabling SVOM boot watchdog functionality" on page 89
