Fujitsu PRIMERGY RX2530 M1 Upgrade And Maintenance Manual

RX2530 M1 Upgrade and Maintenance Manual 247
Processors
Figure 168: Closing socket release lever 2
Ê Fully close and hold shut the load plate.
Ê Close the socket release lever 2 marked Close 1st and latch it under the load
plate retention tab to lock down the load plate.
I Regard that the socket release lever 2 close the load plate correctly.
