Fujitsu PRIMERGY RX2530 M1 Upgrade And Maintenance Manual

30 Upgrade and Maintenance Manual RX2530 M1
Before you start
Phillips
PH1 / (+) No. 1
0.06 Nm
UFM nylon
screw
M3 x 4.5 mm
(white)
A3C40109082
Phillips
PH1 / (+) No. 1
0.4 Nm
TFM
M2.5 x 4 mm
(silver)
A3C40137316
Hexagon bolt
0.6 Nm
Front VGA
connector,
serial interface
UNC #4-40
(silver)
V26827-B408-V989
Phillips
PH1 / (+) No. 1
0.4 Nm
Front panel on
QRL
M2.5 x 8 mm
(silver)
C26192-Y10-C174
SW5
0.6 Nm
DynamicLoM
module
(D3245,
D3255)
M3 x 5 mm
(silver)
C26192-Y1-C65
SW5
0.6 Nm
DynamicLoM
module
(D3265,
D3275)
M3 x 8 mm
(silver)
C26192-Y1-C66
Screw driver /
Bit insert
Torque
Screw Usage Type
Table 2: List of used screws (not applicable for the Japanese market)
