GE Vivid 7 - Page 227

GE HEALTHCARE
DIRECTION FC091194, REVISION 11 VIVID 7 SERVICE MANUAL
Chapter 3 - System Setup 3 - 103
3-10-10-2 Query/Retrieve Setup on the Vivid 7 (cont’d)
In Figure 3-108, the selected dataflow, Query/Retrieve, is shown.
5.) Select QueryRetrieve so it is highlighted and then select Properties to display the Properties dialog.
Figure 3-108 Query/Retrieve workflow
Figure 3-109 Select Query/Retrieve’s Properties
SELECT
QUERY RETRIEVE AND THEN
SELECT PROPERTIES
QUERY RETRIEVE
PROPERTIES DIALOG
