GE HEALTHCARE
DIRECTION FC091194, REVISION 11 VIVID 7 SERVICE MANUAL
Chapter 4 - Functional Checks 4 - 75
4-3-20-3 VCR Checks
4-3-20-4 VCR Counter Check
When adding new examinations to a Video cassette, you can set the VCR Counter without rewinding
the Video Cassette to the start. The procedure below explains how to check this function.
Prerequisite:
The VCR Counter number when the Video Cassette was Ejected last time.
Figure 4-40 VCR Controls on the Operator Panel
Table 4-37 VCR Counter Check
Step Task Expected Result(s)
1.
Insert the Video cassette in the VCR
2.
Press VIDEO
on the Operator Panel. To start the video counter at a different point:
3.
Press UPDATE MENU
in the Trackball area.
The Video Set Counter / Search Dialog window is
displayed
4.
Use the alphanumeric keyboard to enter the counter
number (from last time) in the counter field.
Number appears on the screen
5.
Press Set Counter to save the change. Number is saved
6.
Press VIDEO on the Operator Panel, to return to
scanning mode.
The system returns to the scanning mode
Mode Dependant
Keys
Stop,
Pause,
Rewind
Fast Forward
Record/Pause
