8.13 AT^SMONP
 EHS6_ATC_V03.001 15/12/3
Confidential / Released
Page 192 of 513
• In case of a 3G serving cell:


Columns for GSM (2G) parameters:


Columns for UMTS (3G) parameters:
Syntax:
3G:
UARFCN
1
,PSC
1
,EC/n0
1
,RSCP
1
,SQual
1
,SRxLev
1
,set
1
,rank
1
UARFCN
2
,PSC
2
,EC/n0
2
,RSCP
2
,SQual
2
,SRxLev
2
,set
2
,rank
2
...
UARFCN
n
,PSC
n
,EC/n0
n
,RSCP
n
,,SQual
n
,SRxLev
n
,set
n
,rank
n
2G:
ARFCN
1
,RSSI
1
,NCC
1
,BCC
1
,SRxLev
1
,rank
1
ARFCN
2
,RSSI
2
,NCC
2
,BCC
2
,SRxLev
2
,rank
2
...
ARFCN
n
,RSSI
n
,NCC
n
,BCC
n
,SRxLev
n
,rank
n
Example:
3G:
10786,49,-7.0,-75,22,37,AS,-9
10786,161,-24.0,-121,0,0,--,0
10786,54,-24.0,-121,0,0,--,0
10786,51,-24.0,-121,0,0,--,0
10786,62,-24.0,-121,0,0,--,0
10786,159,-24.0,-121,0,0,--,0
2G:
----,----,-,-,----,------
OK
Column Description
ARFCN Absolute Radio Frequency Channel Number of the BCCH carrier
rs RSSI value 0 - 63 (RSSI = Received signal strength indication)
dBm Receiving level in dBm
MCC Mobile Country Code (first part of the PLMN code)
MNC Mobile Network Code (second part of the PLMN code)
NCC Network colour Code
BCC Base Station colour code
C1 cell selection criterion
C2 cell reselection criterion
LAC Location area code
cell Cell identifier
C31 cell reselection criterion
C32 cell reselection criterion
SRxLev RX level value for base station selection in dB (see 3GPP 25.304)
rank Rank of this cell as neighbor for inter-RAT cell reselection
