Cinterion
®
EHS6 AT Command Set
8.12 AT^SMONI
EHS6_ATC_V03.001 15/12/3
Confidential / Released
Page 182 of 513
8.12 AT^SMONI Monitoring Serving Cell
The AT^SMONI command supplies information of the serving cell.
Syntax
Notes
• The parameters LAC and cell are presented as hexadecimal digits, the remaining parameters are composed
of decimal digits.
• If the BS supports frequency hopping during a connection, the dedicated channel (ARFCN) is not stable. This
mode is indicated by chann = 'h'.
• It may happen for a short time that following parameters have no values after an inter-system change from
GSM to UMTS: EC/n0, RSCP, SQual and SRxLev. In this case these parameter values are displayed with the
"-" character.
• The service state 'SEARCH' (Searching) could mean a PLMN search or a cell search. This can also happen
for a short time when ME is leaving connected mode.
8.12.1 AT^SMONI Responses
ME is not connected:
• ME is camping on a GSM (2G) cell:
• ME is camping on a UMTS (3G) cell:
Test Command
AT^SMONI=?
Response(s)
OK
Exec Command
AT^SMONI
Response(s)
See: Section 8.12.1, AT^SMONI Responses
OK
Write Command
AT^SMONI=255
Response(s)
See: Section 8.12.2, AT^SMONI Enhanced Responses
OK
ERROR
+CME ERROR: <err>
PIN Last
- - -
Syntax:
^SMONI: ACT,ARFCN,BCCH,MCC,MNC,LAC,cell,C1,C2,NCC,BCC,GPRS,ARFCN,TS,timAdv,dBm,Q,ChMod
Example:
^SMONI: 2G,71,-61,262,02,0143,83BA,33,33,3,6,G,NOCONN
Syntax:
^SMONI: ACT,UARFCN,PSC,EC/n0,RSCP,MCC,MNC,LAC,cell,SQual,SRxLev,PhysCh, SF,Slot,EC/
n0,RSCP,ComMod,HSUPA,HSDPA
