Cinterion
®
EHS6 AT Command Set
8.12 AT^SMONI
EHS6_ATC_V03.001 15/12/3
Confidential / Released
Page 183 of 513
• ME is searching and could not (yet) find a suitable GSM (2G) cell:
• ME is searching and could not (yet) find a suitable UMTS (3G) cell:
ME has a dedicated channel (for example call in progress):
• GSM (2G) cell:
• UMTS (3G) cell:
Columns for GSM (2) Serving Cell parameters:
Columns for UMTS (3G) Serving Cell parameters:
Example:
^SMONI: 3G,10564,296,-7.5,-79,262,02,0143,00228FF,-92,-78,NOCONN
Syntax:
^SMONI: ACT,ARFCN,BCCH,MCC,MNC,LAC,cell,C1,C2,NCC,BCC,GPRS,ARFCN,TS,timAdv,dBm,Q,ChMod
Example:
^SMONI: 2G,SEARCH,SEARCH
Syntax:
^SMONI: ACT,UARFCN,PSC,EC/n0,RSCP,MCC,MNC,LAC,cell,SQual,SRxLev,PhysCh, SF,Slot,EC/
n0,RSCP,ComMod,HSUPA,HSDPA
Example:
^SMONI: 3G,SEARCH,SEARCH
Syntax:
^SMONI: ACT,ARFCN,BCCH,MCC,MNC,LAC,cell,C1,C2,NCC,BCC,GPRS,ARFCN,TS,timAdv,dBm,Q,ChMod
Example:
^SMONI: 2G,673,-80,262,07,4EED,A500,35,35,7,4,G,643,4,0,-80,0,S_FR
Syntax:
^SMONI: ACT,UARFCN,PSC,EC/n0,RSCP,MCC,MNC,LAC,cell,SQual,SRxLev,PhysCh, SF,Slot,EC/
n0,RSCP,ComMod,HSUPA,HSDPA
Example:
^SMONI: 3G,10737,131,-5,-93,260,01,7D3D,C80BC9A,21,11,EDCH,256,4,-5,-93,0,01,06
Column Description
ACT Access Technology
ARFCN ARFCN (Absolute Radio Frequency Channel Number) of the BCCH carrier
BCCH Receiving level of the BCCH carrier in dBm (level is limited from -110dBm to -
47dBm)
MCC Mobile Country Code (first part of the PLMN code)
MNC Mobile Network Code (second part of the PLMN code)
LAC Location Area Code
cell Cell ID
C1 Coefficient for base station selection
C2 Coefficient for base station selection
NCC PLMN colour code
BCC Base station colour code
GPRS GPRS state
