Cinterion
®
EHS6 AT Command Set
8.13 AT^SMONP
EHS6_ATC_V03.001 15/12/3
Confidential / Released
Page 191 of 513
Columns for UMTS (3G) parameters:
8.13.2 AT^SMONP Enhanced Responses
Responses of write command AT^SMONP=255:
• In case of a GSM (2G) serving cell:
NCC Network colour Code
BCC Base Station colour code
C1 cell selection criterion
C2 cell reselection criterion
LAC Location area code
cell Cell identifier
Column Description
UARFCN UTRAN Absolute Radio Frequency Channel Number of the BCCH carrier
PSC Primary Scrambling Code
EC/n0 Carrier to noise ratio in dB = measured Ec/Io value in dB. Please refer to 3GPP
25.133, section 9.1.2.3, Table 9.9 for details on the mapping from EC/n0 to EC/Io.
RSCP Received Signal Code Power in dBm
SQual Quality value for base station selection in dB (see 3GPP 25.304)
SRxLev RX level value for base station selection in dB (see 3GPP 25.304)
Syntax:
2G:
ARFCN
1
,rs
1
,dBm
1
,MCC
1
,MNC
1
,NCC
1
,BCC
1
,C1
1
,C2
1
,LAC
1
,cell
1
,C31
1
,C32
1
ARFCN
2
,rs
2
,dBm
2
,MCC
2
,MNC
2
,NCC
2
,BCC
2
,C1
2
,C2
2
,LAC
2
,cell
2
,C31
2
,C32
2
...
ARFCN
n
,rs
n
,dBm
n
,MCC
n
,MNC
n
,NCC
n
,BCC
n
,C1
n
,C2
n
,LAC
n
,cell
n
,C31
n
,C32
n
3G:
UARFCN
1
,PSC
1
,EC/n0
1
,RSCP
1
UARFCN
2
,PSC
2
,EC/n0
2
,RSCP
2
...
UARFCN
n
,PSC
n
,EC/n0
n
,RSCP
n
Example:
2G:
658,51,-60,262,07,7,4,46,46,4EED,08B8,0,0
666,47,-64,262,07,7,1,42,42,4EED,A500,0,0
1006,37,-74,262,07,7,4,32,32,4EED,----,0,0
1021,36,-75,262,07,7,1,31,21,4EED,08B2,0,0
702,33,-78,262,07,7,3,28,28,4EED,A4F0,0,0
654,32,-79,262,07,7,5,27,27,4EED,1C3A,0,0
3G:
-----,---,-----,----
OK
