Gemalto Cinterion EHS6 User Manual

Cinterion
®
EHS6 AT Command Set 
8.13 AT^SMONP
 EHS6_ATC_V03.001 15/12/3
Confidential / Released
Page 190 of 513
• In case of a UMTS (3G) serving cell:


Columns for GSM (2G) parameters:
UARFCN
2
,PSC
2
,EC/n0
2
,RSCP
2
...
UARFCN
n
,PSC
n
,EC/n0
n
,RSCP
n
Example:
2G:
658,50,-61,262,07,7,4,45,45,4EED,08B8
666,48,-63,262,07,7,1,43,43,4EED,A500
1006,39,-72,262,07,7,4,34,34,4EED,----
1021,36,-75,262,07,7,1,31,21,4EED,08B2
702,32,-79,262,07,7,3,27,27,4EED,A4F0
654,30,-81,262,07,7,5,25,25,4EED,1C3A
3G:
-----,---,-----,----
OK
Syntax:
3G:
UARFCN
1
,PSC
1
,EC/n0
1
,RSCP
1
,SQual
1
,SRxLev
1
UARFCN
2
,PSC
2
,EC/n0
2
,RSCP
2
,SQual
2
,SRxLev
2
...
UARFCN
n
,PSC
n
,EC/n0
n
,RSCP
n
,SQual
n
,SRxLev
n
2G:
ARFCN
1
,RSSI
1
,NCC
1
,BCC
1
,SRxLev
1
ARFCN
2
,RSSI
2
,NCC
2
,BCC
2
,SRxLev
2
...
ARFCN
n
,RSSI
n
,NCC
n
,BCC
n
,SRxLev
n
Example:
3G:
10786,49,-5.5,-78,25,34
10786,161,-24.0,-121,0,0
10786,54,-24.0,-121,0,0
10786,51,-24.0,-121,0,0
10786,62,-24.0,-121,0,0
10786,159,-24.0,-121,0,0
2G:
----,----,-,-,----
OK
Column Description
ARFCN Absolute Radio Frequency Channel Number of the BCCH carrier
rs RSSI value 0 - 63 (RSSI = Received signal strength indication)
dBm Receiving level in dBm
MCC Mobile Country Code (first part of the PLMN code)
MNC Mobile Network Code (second part of the PLMN code)
