Cinterion
®
EHS6 AT Command Set
8.12 AT^SMONI
EHS6_ATC_V03.001 15/12/3
Confidential / Released
Page 187 of 513
Columns for GSM (2G) Dedicated Channel parameters:
Columns for UMTS (3G) Dedicated Channel parameters:
Note: Physical channels in downlink are considered.
8.12.3 Service states
Depending on the service state, an additional textual output is generated (refer also to the response examples):
• "SEARCH" (Searching) - The MS is searching, but could not (yet) find a suitable cell. This output appears
after restart of the MS or after loss of coverage.
• "NOCONN" (No connection) - The MS is camping on a cell and registered to the network. The service state
is 'idle', i.e. there is no connection established or a dedicated channel in use.
• "LIMSRV" (Limited Service) - The MS is camping on a cell but not registered to the network. Only emergency
calls are allowed. The MS enters this state, for example, when
SQual Quality value for base station selection in dB (see 3GPP 25.304)
SRxLev RX level value for base station selection in dB (see 3GPP 25.304)
Column Description
ARFCN ARFCN (Absolute Radio Frequency Channel Number) of the BCCH carrier
TS Timeslot number
timAdv Timing advance in bits
dBm Receiving level of the traffic channel carrier in dBm
Q Receiving quality (0-7)
ChMod Channel mode (--: Signalling, S_HR: Half rate, S_FR: Full rate, S_EFR: Enhanced
Full Rate, A_HR: AMR Half rate, A_FR: AMR Full rate )
Column Description
PhysCh Physical Channel Type (DPCH, FDPCH)
SF Spreading Factor (4,8,16,32,64,128,256,512)
Slot Slot Format for DPCH (0-16) (see 3GPP TS 25.211 V7.10.0 Table 11)
Slot Format for FDPCH (0-9) (see 3GPP TS 25.211 V7.10.0 Table 16C)
EC/n0 Carrier to noise ratio in dB
RSCP Received Signal Code Power in dBm
ComMod Compressed Mode (0-1) (indicates valid transmission gap pattern)
HSUPA HSUPA Status (a.k.a. E-DCH Status) indicated by xy:
x = Cell Capability Indicator: 0 - HSUPA capability not indicated, 1 - HSUPA Capa-
ble Cell. Please consider that some providers/MNOs don't support this flag and
that it is provided "for display indication only", see 3GPP TS 25.331 [42] (later than
version 6.9.0) section 10.2.48.8.8.
y = ME Call Status: 0 - HSUPA inactive, 1 - HSUPA active
HSDPA HSDPA Status indicated by xy:
x = Cell Capability Indicator: 0 - HSDPA capability not indicated, 1 - HSDPA Capa-
ble Cell. Please consider that some providers/MNOs don't support this flag and
that it is provided "for display indication only", see 3GPP TS 25.331 [42] (later than
version 6.8.0), section 10.2.48.8.8.
y = ME Call Status: 0 - HSDPA inactive, 1 - HSDPA suspended, 2 - HSDPA active
Column Description
