Cinterion
®
EHS6 AT Command Set
19.5 AT^SLED
EHS6_ATC_V03.001 15/12/3
Confidential / Released
Page 457 of 513
19.5 AT^SLED LED Feature
AT^SLED controls the LED function provided by the EHS6's STATUS pin, which acts as an output and can be
used to control a connected LED.
The AT^SLED command is functional only if LED functionality is enabled with AT^SCFG="Gpio/mode/SYNC" set
to "std". The electrical specifications of the status pin and advice on how to connect the LED circuit can be found
in [2]. The LED indicates the operating states listed below:
Table 19.1: EHS6 Status and Mode Indication via LED
Syntax
Parameter Description
LED operating mode
0
(&F)
LED feature is disabled.
EHS6 Status <mode>=1 <mode>=2
<flash>= default
<mode>=2
<flash>= user
defined
- GSM CS data call in progress or established
- GSM voice call in progress or established
- UMTS voice call in progress or established
- UMTS CS data call in progress
Permanently on 10 ms on /
990 ms off
<flash> ms on /
990 ms off
- GSM PS data transfer
- UMTS data transfer
Permanently on 10 ms on /
1990 ms off
<flash> ms on /
1990 ms off
ME registered to a network. No call, no data
transfer
Permanently on 10 ms on /
3990 ms off
<flash> ms on /
3990 ms off
Limited Network Service (e.g. because no SIM/
USIM, no PIN or during network search)
500ms on /
500 ms off
500ms on /
500 ms off
500ms on /
500 ms off
Test Command
AT^SLED=?
Response(s)
^SLED: (list of supported <mode>s), (range of supported <flash>s)
OK
Read Command
AT^SLED?
Response(s)
^SLED: <mode>[, <flash>]
OK
Write Command
AT^SLED=<mode>[, <flash>]
Response(s)
OK
ERROR
+CME ERROR: <err>
PIN Last
- + -
<mode>
(num)(&W)
