Cinterion
®
EHS6 AT Command Set
19.4 AT^SCTM
EHS6_ATC_V03.001 15/12/3
Confidential / Released
Page 456 of 513
Unsolicited Result Codes
URC 1
URCs will be sent to the TE when the temperature reaches or exceeds the critical level, or when it is back to
normal.
^SCTM_B: <UrcCause>
URC 2
URC indicated after "^SCTM_B" URC with <UrcCause> value 2 or -2 before the ME switches off.
^SHUTDOWN
Parameter Description
URC presentation mode
0
(P)
Disable URC presentation (except for <UrcCause> equal to -2 or +2).
1 Enable URC presentation.
-2 Below lowest temperature limit (causes immediate switch-off)
-1 Below low temperature alert limit
0 Normal operating temperature
1 Above upper temperature alert limit
2 Above uppermost temperature limit (causes immediate switch-off)
0
(P)
Suppress output of <temp> in read command.
1 Output <temp> in read command.
Board temperature in Celsius. Is comprised between the lowest temperature warning level and the uppermost
temperature warning level.
Examples
EXAMPLE 1
URCs issued when the operating temperature is out of range:
EXAMPLE 2
URCs issued when the temperature is back to normal (URC is output once):
<UrcMode>
(num)
<UrcCause>
(num)
<tempCtrl>
(num)
<temp>
(num)
^SCTM_B: 1
Caution: Module close to overtemperature limit.
^SCTM_B: 2
Alert: Module is above overtemperature limit and switches off.
^SCTM_B: -1
Caution: Module close to undertemperature limit.
^SCTM_B: -2
Alert: Module is below undertemperature limit and switches off.
^SCTM_B: 0
Module back to normal temperature.
