EHS6 AT Command Set 

20.7 AT^SPIO

 EHS6_ATC_V03.001 15/12/3

Confidential / Released

Page 484 of 513

20.7 AT^SPIO GPIO Driver Open/Close

AT^SPIO is implemented for compatibility reasons only, and has no effect. 

Syntax



Parameter Description

0 Close General purpose I/O driver

1 Open General purpose I/O driver

Test Command

AT^SPIO=?

Response(s)

^SPIO:(list of supported <mode>s)

Write Command

AT^SPIO=<mode>

Response(s)

ERROR

+CME ERROR: <err>

PIN  Last

- + -

<mode>

(num)

Default Chapter3
