19.6 AT^SRADC Configure and Read ADC Measurement
The AT^SRADC command controls the module's Analog-to-Digital Converter. The ADC can be used to measure
the voltage of external devices connected to the ADC input. AT^SRADC configures the parameters required for
ADC measurement and returns the measurement result(s). The value(s) can be delivered once on request by
using the single measurement mode, or periodically by specifying the measurement interval. 
Syntax

Unsolicited Result Code
ADC measurement URC (only used in periodic measurement mode). URC indicating the used channel, the num-
ber of measured samples and the voltage. Applies only if periodic measurement mode is enabled.
^SRADC: <count>, <value>[, <value>[, <value>[, <value>[, <value>[, <value>[,
<value>[, <value>[, <value>[, <value>[, <value>]]]]]]]]]]

Parameter Description
ADC channel
Test Command
AT^SRADC=?
Response(s)
^SRADC:(list of supported <op>s), (list of supported <it>s)
OK
Read Command
AT^SRADC?
Response(s)
^SRADC: <op>, <it>
OK
ERROR
+CME ERROR: <err>
Write Command
Single measurement. Requires <op>=1, implies no interval (<it>=0).
AT^SRADC=<op>
Response(s)
^SRADC: <count>, <value>
OK
ERROR
+CME ERROR: <err>
Write Command
Periodic measurement. Requires <op>=1 and <it>=100ms...30000ms
AT^SRADC=<op>, <it>
Response(s)
OK
ERROR
+CME ERROR: <err>
