Gemalto Cinterion EHS6 User Manual

Cinterion
®
EHS6 AT Command Set 
16.5 AT^SAIC
 EHS6_ATC_V03.001 15/12/3
Confidential / Released
Page 397 of 513
16.5 AT^SAIC Audio Interface Configuration
AT^SAIC configures the audio interface. The write command works in all audio modes from 1 to 10. 
Syntax

Parameter Description
Input and output selection
1
(P)
Digital input and output 
The Digital Audio Interface (DAI) can only be enabled when DAI resources are
available (AT^SCFG="GPIO/mode/DAI","std"). Otherwise the AT^SAIC write
command will respond "+CME ERROR: operation not allowed".
Parameter is mandatory if <io>=1 (digital).
0
(P)
Master mode
1Slave mode
Parameter is mandatory if <io>=1 (digital).
0
(P)
Long frame
1 Short frame
Test Command
AT^SAIC=?
Response(s)
^SAIC:(list of supported <io>s),,,,(list of supported<mode>s), (list of supported<frame_mode>s), (list of
supported<clkopt>s), (list of supported<sample_rate>s), (list of supported<sample_format>s)"
OK
Read Command
AT^SAIC?
Response(s)
^SAIC: <io>,"","","", <mode>, <frame_mode>, <clkopt>, <sample_rate>, <sample_format>
OK
ERROR
+CME ERROR: <err>
Write Command
AT^SAIC=<io>,"","","", <mode>, <frame_mode>, <clkopt>, <sample_rate>, <sample_format>
Response(s)
OK
ERROR
+CME ERROR: <err>
PIN  Last
- + -
<io>
(num)
<mode>
(num)
<frame_mode>
(num)
