Cinterion
®
EHS6 AT Command Set
8.12 AT^SMONI
EHS6_ATC_V03.001 15/12/3
Confidential / Released
Page 186 of 513
• UMTS (3G) cell:
Columns for GSM (2G) Serving Cell parameters:
Columns for UMTS (3G) Serving Cell parameters:
Syntax:
^SMONI:
ACT,ARFCN,BCCH,MCC,MNC,LAC,cell,C1,C2,NCC,BCC,GPRS,PWR,RXLev,ARFCN,TS,timAdv,dBm,Q,ChM
od
Example:
^SMONI: 2G,852,-80,262,03,4E2D,6C2D,28,32,3,5,E,0,-104,816,1,3,-71,0,A_FR
Syntax:
^SMONI: ACT,UARFCN,PSC,EC/n0,RSCP,MCC,MNC,LAC,cell,SQual,SRxLev,PhysCh, SF,Slot,EC/
n0,RSCP,ComMod,HSUPA,HSDPA
Example:
^SMONI: 3G,10737,131,-5,-93,260,01,7D3D,C80BC9A,21,11,DPCH,256,4,-5,-93,0,00,00
Column Description
ACT Access Technology
ARFCN ARFCN (Absolute Radio Frequency Channel Number) of the BCCH carrier
BCCH Receiving level of the BCCH carrier in dBm (level is limited from -110dBm to -
47dBm)
MCC Mobile Country Code (first part of the PLMN code)
MNC Mobile Network Code (second part of the PLMN code)
LAC Location Area Code
cell Cell ID
C1 Coefficient for base station selection
C2 Coefficient for base station selection
NCC PLMN colour code
BCC Base station colour code
GPRS GPRS state
PWR Maximal power level used on RACH channel in dBm
RxLev Minimal receiving level (in dBm) to allow registration
Column Description
ACT Access Technology
UARFCN UARFCN (UTRAN Absolute Radio Frequency Channel Number) of the BCCH car-
rier
PSC Primary Scrambling Code
EC/n0 Carrier to noise ratio in dB = measured Ec/Io value in dB. Please refer to 3GPP
25.133, section 9.1.2.3, Table 9.9 for details on the mapping from EC/n0 to EC/Io.
RSCP Received Signal Code Power in dBm
MCC Mobile Country Code (first part of the PLMN code)
MNC Mobile Network Code (second part of the PLMN code)
LAC Location Area Code, see note
cell Cell ID
