8.12 AT^SMONI
EHS6_ATC_V03.001 15/12/3
Confidential / Released
Page 184 of 513
Columns for GSM (2G) Dedicated Channel parameters:
Columns for UMTS (3G) Dedicated Channel parameters:
Note: Physical channels in downlink are considered.
Column Description
ACT Access Technology
UARFCN UARFCN (UTRAN Absolute Radio Frequency Channel Number) of the BCCH car-
rier
PSC Primary Scrambling Code
EC/n0 Carrier to noise ratio in dB = measured Ec/Io value in dB. Please refer to 3GPP
25.133, section 9.1.2.3, Table 9.9 for details on the mapping from EC/n0 to EC/Io.
RSCP Received Signal Code Power in dBm
MCC Mobile Country Code (first part of the PLMN code)
MNC Mobile Network Code (second part of the PLMN code)
LAC Location Area Code
cell Cell ID
SQual Quality value for base station selection in dB (see 3GPP 25.304)
SRxLev RX level value for base station selection in dB (see 3GPP 25.304)
Column Description
ARFCN ARFCN (Absolute Radio Frequency Channel Number) of the BCCH carrier
TS Timeslot number
timAdv Timing advance in bits
dBm Receiving level of the traffic channel carrier in dBm
Q Receiving quality (0-7)
ChMod Channel mode (--: Signalling, S_HR: Half rate, S_FR: Full rate, S_EFR: Enhanced
Full Rate, A_HR: AMR Half rate, A_FR: AMR Full rate )
Column Description
PhysCh Physical Channel Type (DPCH, FDPCH)
SF Spreading Factor (4,8,16,32,64,128,256,512)
Slot Slot Format for DPCH (0-16) (see 3GPP TS 25.211 V7.10.0 Table 11)
Slot Format for FDPCH (0-9) (see 3GPP TS 25.211 V7.10.0 Table 16C)
EC/n0 Carrier to noise ratio in dB
RSCP Received Signal Code Power in dBm
ComMod Compressed Mode (0-1) (indicates valid transmission gap pattern)
