6 System Functions
System
Remote Command
:CALibration:REFerence:CLOCk?
Example :CAL:REF:CLOC:INIT?
//connect cable
:CAL:REF:CLOC?
//disconnect cable
:CAL:REF:CLOC:END?
Notes :CALibration:REFerence:CLOCk? returns 0 if successful
:CALibration:REFerence:CLOCk? returns 1 if failed
Dependencies Option DP2 or B40
Couplings Initializes the time for the Last Characterize Reference Clock Time.
Records the temperature for the Last Characterize Reference Clock Temperature. Expected to be run
after :CAL:REF:CLOC:INIT, and before :CAL:REF:CLOC:END.
Initial S/W Revision A.13.00
Parameter Name Characterize Reference Clock Initialization
Mode All
Remote Command
:CALibration:REFerence:CLOCk:INITialize?
Example :CAL:REF:CLOC:INIT?
Notes :CALibration:REFerence:CLOCk:INIT? returns 0 if successful
:CALibration:REFerence:CLOCk:INIT? returns 1 if failed
Dependencies Option DP2 or B40
Couplings Expected to be run before sending the :CAL:REF:CLOC? command. This will stop the current
measurement when it has completed (does not abort the current data acquisition), and it will prepare
the instrument for the expected cabling.
Force Restart Yes
Initial S/W Revision A.12.00
Parameter Name Characterize Reference Clock End
Mode All
Remote Command
:CALibration:REFerence:CLOCk:END?
Example :CAL:REF:CLOC:END?
Notes :CALibration:REFerence:CLOCk:END? returns 0 if successful
:CALibration:REFerence:CLOCk:END? returns 1 if failed
Dependencies Option DP2 or B40
Couplings Expected to be run after sending the :CAL:REF:CLOC? command, and after removing the cable used
in that Characterize Reference Clock step. This will resume any queued measurements, and it
concludes the reference clock characterization.
Force Restart Yes
Initial S/W Revision A.12.00
EMI Receiver Mode Reference 317
