9 Strip Chart Measurement
Remote Command Results
Command N Results Returned
INITiate:SCHart n/a n/a
CONFigure? n/a name of current measurement: " SCHart "
CONFigure:SCHart n/a n/a (selects Strip Chart measurement in Meas Preset state)
INITiate:SCHart n/a n/a (selects Strip Chart measurement without affecting settings)
FETCh:SCHart [n]?
MEASure:SCHart [n]?
READ:SCHart [n]?
Not specified
or n=1
Return the following comma-separated scalar results:
1. Current measurement result of Meter 1
2. Current measurement result of Meter 2
3. Current measurement result of Meter 3
Note : Return NaN (9.91E37) if the Meter is not available.
n=2 Return the following comma-separated scalar results:
1. Max measurement result of Meter 1
2. Max measurement result of Meter 2
3. Max measurement result of Meter 3
Note : Return NaN (9.91E37) if the Meter is not available.
n=3 This query returns Trace 1 data as a list of x,y pairs. The y-values are in the
current Y-Axis Unit of the analyzer. The x-axis values are the values of
the trace, in the x-axis scale units of the trace (Hz for frequency domain
traces, seconds for time domain traces).
n=4 Returns Trace 2 data as a series of x,y pairs
n=5 Returns Trace 3 data as a series of x,y pairs
Key Path
Meas
Initial S/W Revision A.07.00
EMI Receiver Mode Reference 607
