Function
The input signals of this function block are copied to the 8-byte user data of the CAN object 2 and
assigned to the system bus. The meaning of the user data can be determined very easily with
C0864/2 and C0865/2 and the corresponding configuration code (CFG).
Byte 1, 2, 3, and 4
The meaning of these user data can be selected among different signal types. According to the
requirement up to two analog signals, 32 digital signals from the function block FDO or one phase
signal can be selected. Mixes forms are also possible.
Byte 5 and 6
Here, the analog signal configured at the CAN-OUT2.W3 input is mapped.
Byte 7 and 8
Here, the analog signal configured at the CAN-OUT2.W4 input is mapped.
