LMI Technologies Gocator 2300 Series User Manual

Gocator 2300 & 2880 Series
Gocator Web Interface • Measurement • 195
Measurement Panel
Measurement Illustration
Angle X
Determines the X angle of the surface with respect to
the alignment target.
Angle Y
Determines the Y angle of the surface with respect to
the alignment target.
Offset Z
Determines the z offset of the surface with respect to
the alignment target.
Measurements
Parameter Description
Decision See Decisions on page 139.
Region See Regions on page 139.
Output See Filters on page 141.
Parameters
