LMI Technologies Gocator 2300 Series User Manual

Gocator 2300 & 2880 Series
Gocator Device Files • Job Files • 267
Element Type Description
1 – Enable
HoldEnabled Boolean
Output hold enable state:
0 – Disable
1 – Enable
SmoothingEnabled Boolean
Smoothing enable state:
0 – Disable
1 – Enable
SmoothingWindow 32u Smoothing window.
Scale 64f Output scaling factor.
Offset 64f Output offset factor.
DecisionMin 64f Minimum decision threshold.
DecisionMax 64f Maximum decision threshold.
Absolute
Boolean
Setting for selecting absolute or signed result:
0 – Signed
1 – Absolute
ProfilePosition
A ProfilePositionelement defines settings for a profile position tool and one or more of its
measurements.
Element Type Description
Name String Tool name.
Source 32s Profile source.
Anchor\X String (CSV) The X measurements (IDs) used for anchoring.
Anchor\X.options String (CSV) The X measurements (IDs) available for anchoring.
Anchor\Z String (CSV) The Z measurements (IDs) used for anchoring.
Anchor\Z.options String (CSV) The Z measurements (IDs) available for anchoring.
Feature
ProfileFeature
Element for feature detection.
Measurements\X Position tool
measurement
X measurement.
Measurements\Z Position tool
measurement
Z measurement.
ProfilePositionChild Elements
Element Type Description
id (attribute) 32s Measurement ID. Optional (measurement disabled if not
set).
Name String Measurement name.
Position Tool Measurement
