Gocator 2300 & 2880 Series
Gocator Device Files • Job Files • 293
Field Type Offset Description
1 – Bottom
width 32u 5 Width of model space, in units of xScale
length 32u 9 Length of model space, un units of yScale
xScale 32u 13 X scale (nm)
yScale 32u 17 Y scale (nm)
xOffset 32s 21 X offset (µm)
yOffset 32s 25 Y offset µm
zAngle 32s 29 Z rotation (microdegrees)
pointCount 32u 33 Number of edge points
points[pointCount] (32u, 32u) 37 Edge points collection. Each point is a tuple of x and y values, in
units of xScale and yScale, respectively.
Configuration
Delete this text and replace it with your own content.
Element Type Description
@version 32u Major version (1).
@versionMinor 32u Minor version (0).
Edges Collection Collection of Edge items (described below).
EdgeSensitivity 64f Sensitivity recorded during model edges generation (read-only).
TransformedDataRegion Region3d Data region of the model.
ZAngle 64f Additional rotation applied to the model (degrees).
TargetEdgeSensitivity 64f Sensitivity used to generate target edges.
ImageType 32s
Selects type of image used to generate edges:
0 – Height map
1 – Intensity map
ImageType.options 32s (CSV) List of available image types.
Configuration Child Elements
