LMI Technologies Gocator 2300 Series User Manual

Gocator 2300 & 2880 Series
Gocator Device Files • Job Files • 281
Element Type Description
id (attribute) 32s Measurement ID. Optional (measurement disabled if not
set).
Name String Measurement name.
Enabled Boolean
Measurement enable state:
0 – Disable
1 – Enable
HoldEnabled Boolean
Output hold enable state:
0 – Disable
1 – Enable
SmoothingEnabled Boolean
Smoothing enable state:
0 – Disable
1 – Enable
SmoothingWindow 32u Smoothing window.
Scale 64f Output scaling factor.
Offset 64f Output offset factor.
DecisionMin 64f Minimum decision threshold.
DecisionMax 64f Maximum decision threshold.
Position Tool Measurement
SurfaceStud
A SurfaceStudelement defines settings for a surface stud tool and one or more of its measurements.
Element Type Description
Name String Tool name.
Source 32s Surface source.
Anchor\X String (CSV) The X measurements (IDs) used for anchoring.
Anchor\X.options String (CSV) The X measurements (IDs) available for anchoring.
Anchor\Y String (CSV) The Y measurements (IDs) used for anchoring.
Anchor\Y.options String (CSV) The Y measurements (IDs) available for anchoring.
Anchor\Z String (CSV) The Z measurements (IDs) used for anchoring.
Anchor\Z.options String (CSV) The Z measurements (IDs) available for anchoring.
StudRadius 64f Radius of stud (mm).
StudHeight 64f Height of stud (mm).
BaseHeight 64f Height of stud’s base.
TipHeight 64f Height of stud’s tip.
RegionEnabled Boolean Setting to enable/disable region.
Region
Region3D
Measurement region.
SurfaceStudChild Elements
