Gocator 2300 & 2880 Series
Gocator Device Files • Job Files • 282
Element Type Description
RefRegionsEnabled Boolean
Setting to enable/disable reference regions:
0 – Disable
1 – Enable
RefRegionCount 32s Count of the reference regions that are to be used.
RefRegions (Collection) Reference regions. Contains two RefRegion elements of type
SurfaceRegion2D.
AutoTiltEnabled Boolean
Setting to enable/disable tilt correction:
0 – Disable
1 – Enable
TiltXAngle 64f Setting for manual tilt correction angle X.
TiltYAngle 64f Setting for manual tilt correction angle Y.
Measurements\BaseX Stud tool
measurement
BaseX measurement.
Measurements\BaseY Stud tool
measurement
BaseY measurement.
Measurements\BaseZ Stud tool
measurement
BaseZ measurement.
Measurements\TipX Stud tool
measurement
TipX measurement.
Measurements\TipY Stud tool
measurement
TipY measurement.
Measurements\TipZ Stud tool
measurement
TipZ measurement.
Measurements\Radius Stud tool
measurement
Radius measurement.
Element Type Description
id (attribute) 32s Measurement ID. Optional (measurement disabled if not
set).
Name String Measurement name.
Enabled Boolean
Measurement enable state:
0 – Disable
1 – Enable
HoldEnabled Boolean
Output hold enable state:
0 – Disable
1 – Enable
SmoothingEnabled Boolean
Smoothing enable state:
0 – Disable
Stud Tool Measurement
