Gocator 2300 & 2880 Series
Gocator Device Files • Job Files • 254
Element Type Description
RegionCount 32s Count of the regions.
Regions (Collection) The regions used to calculate a line. Contains one or two Region elements
of type ProfileRegion2D.
ProfileLine Child Elements
ProfileRegion2d
An element of type ProfileRegion2d defines a rectangular area of interest.
Element Type Description
X 64f
Setting for profile region X position (mm).
Z 64f
Setting for profile region Z position (mm).
Width 64f
Setting for profile region width (mm).
Height 64f
Setting for profile region height (mm).
ProfileRegion2d Child Elements
SurfaceTypes
The following types are used by the various measurement tools.
Region3D
An element of type Region3D defines a rectangular area of interest in 3D.
Element Type Description
X 64f Volume X position (mm).
Y 64f Volume Y position (mm).
Z 64f Volume Z position (mm).
Width 64f Volume width (mm).
Length 64f Volume length (mm).
Height 64f Volumeheight (mm).
Region3D Child Elements
SurfaceFeature
An element of type SurfaceFeature defines the settings for detecting a feature within an area of interest.
Element Type Description
Type 32s Setting to determine how the feature is detected within the area:
0 – Average (formerly Centroid 2d)
1 – Centroid (formerly Centroid 3d)
2 – X Min
3 – X Max
4 – Y Min
5 – Y Max
SurfaceFeature Child Elements
