Gocator 2300 & 2880 Series
Gocator Device Files • Job Files • 263
Element Type Description
(X and Z measurements only)
0 – Bottom
1 – Left corner
2 – Right corner
ProfileIntersect
A ProfileIntersectelement defines settings for a profile intersect tool and one or more of its
measurements.
Element Type Description
Name String Tool name.
Source 32s Profile source.
Anchor\X String (CSV) The X measurements (IDs) used for anchoring.
Anchor\X.options String (CSV) The X measurements (IDs) available for anchoring.
Anchor\Z String (CSV) The Z measurements (IDs) used for anchoring.
Anchor\Z.options String (CSV) The Z measurements (IDs) available for anchoring.
RefType 32s
Reference line type:
0 – Fit
1 – X Axis
RefLine
ProfileLine
Definition of reference line. Ignored if RefType is not 0.
Line
ProfileLine
Definition of line.
Measurements\X Intersect tool
measurement
X measurement.
Measurements\Z Intersect tool
measurement
Z measurement.
Measurements\Angle Intersect tool
measurement
Angle measurement.
ProfileIntersect Child Elements
Element Type Description
@id 32s Measurement ID. Optional (measurement disabled if not
set).
Name String Measurement name.
Enabled Boolean
Measurement enable state:
0 – Disable
1 – Enable
HoldEnabled Boolean
Output hold enable state:
0 – Disable
1 – Enable
SmoothingEnabled Boolean
Smoothing enable state:
Intersect Tool Measurement
