LMI Technologies Gocator 2300 Series User Manual

Gocator 2300 & 2880 Series
Specifications • Master 400/800 • 416
Function Pin
Reserved 6
Reserved 7
Reserved 8
Reserved 9
Reserved 10
Reserved 11
Reserved 12
Reserved 13
Reserved 14
Reserved 15
Reserved 16
This connector does not need to be wired up for proper operation.
Function Pin
Encoder_A+ 1
Encoder_A- 2
Encoder_B+ 3
Encoder_B- 4
Encoder_Z+ 5
Encoder_Z- 6
GND 7
+5VDC 8
Encoder (8 pin connector)
Master 400/800 Electrical Specifications
Master 400 / 800
Power Supply Voltage +48VDC
Power Supply current (Max.) 10A
Power Draw (Min.) 15W
Safety Voltage +12 to +48VDC
Encoder signal voltage range RS485 Differential
Digital input voltage range Logical LOW: 0 VDC to +0.1VDC
Logical HIGH: +11 VDC to +22.5VDC
Electrical Specifications for Master 400/800
When using a Master 400/800, its chassis must be well grounded.
