Gocator 2300 & 2880 Series
Gocator Device Files • Job Files • 289
Element Type Description
CurrentMax 64f Maximum current (mA).
CurrentMax.min 64f Minimum value of maximum current (mA).
CurrentMax.max 64f Maximum value of maximum current (mA).
CurrentInvalidEnabled Bool Enables special current value for invalid measurement value.
CurrentInvalid 64f Current value for invalid measurement value (mA).
CurrentInvalid.min 64f Minimum value for invalid current (mA).
CurrentInvalid.max 64f Maximum value for invalid current (mA).
DataScaleMin 64f Measurement value corresponding to minimum current.
DataScaleMax 64f Measurement value corresponding to maximum current.
Delay 64f Output delay (µs or mm, depending on delay domain defined below).
DelayDomain 32s
Output delay domain:
0 – Time (µs)
1 – Encoder (mm)
Measurement 32u Selected measurement source.
Measurement.options 32u (CSV) List of available measurement sources.
The delay specifies the time or position at which the analog output activates. Upon activation,
there is an additional delay before the analog output settles at the correct value.
Serial
The Serial element defines settings for Serial output.
Element Type Description
Protocol 32s
Serial protocol:
0 – ASCII
1 – Selcom
Protocol.options 32s (CSV) List of available protocols.
Selcom Section
See Selcom below.
Ascii Section
See Ascii on the next page.
Measurements 32u (CSV) Selected measurement sources.
Measurements.options 32u (CSV) List of available measurement sources.
Serial Child Elements
Selcom
Element Type Description
Rate 32u Output bit rate.
Rate.options 32u (CSV) List of available rates.
Format 32s
Output format:
Selcom Child Elements
