Gocator 2300 & 2880 Series
Gocator Device Files • Job Files • 283
Element Type Description
1 – Enable
SmoothingWindow 32u Smoothing window.
Scale 64f Output scaling factor.
Offset 64f Output offset factor.
DecisionMin 64f Minimum decision threshold.
DecisionMax 64f Maximum decision threshold.
RadiusOffset
(Radius measurement only)
64f Radius offset of the stud.
SurfaceVolume
A SurfaceVolume element defines settings for a surface volume tool and one or more of its
measurements.
Element Type Description
Name String Tool name.
Source 32s Surface source.
Anchor\X String (CSV) The X measurements (IDs) used for anchoring.
Anchor\X.options String (CSV) The X measurements (IDs) available for anchoring.
Anchor\Y String (CSV) The Y measurements (IDs) used for anchoring.
Anchor\Y.options String (CSV) The Y measurements (IDs) available for anchoring.
Anchor\Z String (CSV) The Z measurements (IDs) used for anchoring.
Anchor\Z.options String (CSV) The Z measurements (IDs) available for anchoring.
RegionEnabled Boolean Setting to enable/disable region.
Region
Region3D
Measurement region.
Measurements\Volume Volume tool
measurement
Volume measurement.
Measurements\Area Volume tool
measurement
Area measurement.
Measurements\Thickness Volume tool
measurement
Thickness measurement.
SurfaceVolume Child Elements
Element Type Description
id (attribute) 32s Measurement ID. Optional (measurement disabled if not
set).
Name String Measurement name.
Enabled Boolean
Measurement enable state:
0 – Disable
1 – Enable
Volume Tool Measurement
