Gocator 2300 & 2880 Series
Gocator Web Interface • Measurement • 171
Parameter Description
When occlusion and exposure causes data drops, users should use the gap filling
function to fill the gaps. See Gap Filling on page 97 for information.
Min Width Specifies the minimum width for a strip to be considered valid.
Tilt Enabled Enables/disables tile correction.
Decision See Decisions on page 139.
Region The measurement region defines the region in which to search for the strip. If possible,
the region should be made large enough to cover the base on the left and right sides of
the strip.
See Regions on page 139 for more information.
Output See Filters on page 141.
Tilt
The strip may be tilted with respect to the sensor's coordinate X axis. This could be caused by conveyor
vibration. If the Tilt option is enabled, the tool will report the width and height measurements following
the tilt angle of the strip.
Script
A Script measurement can be used to program a custom measurement using a simplified C-based
syntax. A script measurement can produce multiple measurement values and decisions for the output.
The Script tool can be used whether Uniform Spacing is enabled or not, that is, with either
resampled or unresampleddata. For more information on the Uniform Spacing setting and
resampled data, see Uniform Spacing (Data Resampling) on page 46.
See Adding and Removing Tools on page 134 for instructions on how to add measurement tools.
See Script Measurement on page 203 for more information on scripts.
