Gocator Device Files • Job Files • 264
Element Type Description
0 – Disable
1 – Enable
SmoothingWindow 32u Smoothing window.
Scale 64f Output scaling factor.
Offset 64f Output offset factor.
DecisionMin 64f Minimum decision threshold.
DecisionMax 64f Maximum decision threshold.
Absolute
(Angle measurement only)
Boolean
Setting for selecting absolute or signed result:
0 – Signed
1 – Absolute
ProfileLine
A ProfileLine element defines settings for a profile line tool and one or more of its measurements.
Element Type Description
Name String Tool name.
Source 32s Profile source.
Anchor\X String (CSV) The X measurements (IDs) used for anchoring.
Anchor\X.options String (CSV) The X measurements (IDs) available for anchoring.
Anchor\Z String (CSV) The Z measurements (IDs) used for anchoring.
Anchor\Z.options String (CSV) The Z measurements (IDs) available for anchoring.
Region
ProfileRegion2d
Measurement region.
Measurements\StdDev Line tool
measurement
StdDev measurement.
Measurements\MaxError Line tool
measurement
MaxError measurement.
Measurements\MinError Line tool
measurement
MinError measurement.
Measurements\Percentile Line tool
measurement
Percentile measurement.
ProfileLine Child Elements
Element Type Description
@id 32s Measurement ID. Optional (measurement disabled if not
set).
Name String Measurement name.
Enabled Boolean
Measurement enable state:
0 – Disable
1 – Enable
Line Tool Measurement
