Gocator 2300 & 2880 Series
Gocator Device Files • Job Files • 246
Tracking
Element Type Description
Enabled Bool Enables tracking.
Enabled.used Bool Whether or not this field is used.
SearchThreshold 64f Percentage of spots that must be found to remain in track.
Height 64f Tracking window height (mm).
Height.min 64f Minimum tracking window height (mm).
Height.max 64f Maximum tracking window height (mm).
Tracking Child Elements
Material
Element Type Description
Type 32s
Type of Material settings to use.
0 – Custom
1 – Diffuse
Type.used Bool Determines if the setting’s value is currently used.
Type.value 32s Value in use by the sensor, useful for determining value when used is
false.
SpotThreshold 32s Spot detection threshold.
SpotThreshold.used Bool Determines if the setting’s value is currently used.
SpotThreshold.value 32s Value in use by the sensor, useful for determining value when used is
false.
SpotWidthMax 32s Spot detection maximum width.
SpotWidthMax.used Bool Determines if the setting’s value is currently used.
SpotWidthMax.value 32s Value in use by the sensor, useful for determining value when used is
false.
SpotWidthMax.min 32s Minimum allowed spot detection maximum value.
SpotWidthMax.max 32s Maximum allowed spot detection maximum value.
SpotSelectionType 32s
Spot selection type
0 – Best. Picks the strongest spot in a given column.
1 – Top. Picks the spot which is most Top/Left on the imager
2 – Bottom. Picks the spot which is most Bottom/Right on the imager
3 – None. All spots are available. This option may not be available in
some configurations.
SpotSelectionType.used Bool Determines if the setting’s value is currently used.
SpotSelectionType.value 32s Value in use by the sensor, useful for determining value when used is
false.
SpotSelectionType.options 32s (CSV) List of available spot selection types.
Material Child Elements
