Gocator Device Files • Job Files • 242
Element Type Description
XSpacingCount 32u Number of points along X when data is resampled.
YSpacingCount 32u Number of points along Y when data is resampled.
TransformedDataRegion
Region3D
Transformed data region of the layout output.
Orientation 32s
Sensor orientation:
0 – Wide
1 – Opposite
2 – Reverse
Orientation.options 32s (CSV) List of available orientation options.
Orientation.value 32s Actual value used if not configurable.
MultiplexBuddyEnabled Bool Enables multiplexing for buddies.
MultiplexSingleEnabled Bool Enables multiplexing for a single sensor configuration.
MultiplexSingleExposureDur
ation
64f Exposure duration in µs (currently rounded to integer when read by the
sensor)
MultiplexSingleDelay 64f Delay in µs. (Currently gets rounded up when read by the sensor.)
MultiplexSinglePeriod 64f Period in µs. (Currently gets rounded up when read by the sensor.)
MultiplexSinglePeriod.min 64f Minimum period in µs.
Element Type Description
X 64f X start(mm).
Y 64f Y start (mm).
Z 64f Z start (mm).
Width 64f X extent (mm).
Length 64f Y extent (mm).
Height 64f Z extent (mm).
Region3D Child Elements
Alignment
The Alignment element contains settings related to alignment and encoder calibration.
Element Type Description
InputTriggerEnabled Bool Enables digital input-triggered alignment operation.
InputTriggerEnabled.used Bool Whether or not this feature can be enabled. This feature is available only
on some sensor models.
InputTriggerEnabled.value Bool Actual feature status.
Type 32s
Type of alignment operation:
0 – Stationary
1 – Moving
Type.options 32s (CSV) List of available alignment types.
Alignment Child Elements
