LMI Technologies Gocator 2300 Series User Manual

Gocator 2300 & 2880 Series
Gocator Device Files • Job Files • 260
Element Type Description
HoldEnabled Boolean
Output hold enable state:
0 – Disable
1 – Enable
SmoothingEnabled Boolean
Smoothing enable state:
0 – Disable
1 – Enable
SmoothingWindow 32u Smoothing window.
Scale 64f Output scaling factor.
Offset 64f Output offset factor.
DecisionMin 64f Minimum decision threshold.
DecisionMax 64f Maximum decision threshold.
ProfileDimension
A ProfileDimension element defines settings for a profile dimension tool and one or more of its
measurements.
Element Type Description
Name String Tool name.
Source 32s Profile source.
Anchor\X String (CSV) The X measurements (IDs) used for anchoring.
Anchor\X.options String (CSV) The X measurements (IDs) available for anchoring.
Anchor\Z String (CSV) The Z measurements (IDs) used for anchoring.
Anchor\Z.options String (CSV) The Z measurements (IDs) available for anchoring.
RefFeature
ProfileFeature
Reference measurement region.
Feature
ProfileFeature
Measurement region.
Measurements\Width Dimension tool
measurement
Width measurement.
Measurements\Height Dimension tool
measurement
Height measurement.
Measurements\Distance Dimension tool
measurement
Distance measurement.
Measurements\CenterX Dimension tool
measurement
CenterX measurement.
Measurements\CenterZ Dimension tool
measurement
CenterZ measurement.
ProfileDimension Child Elements
Element Type Description
@id 32s Measurement ID. Optional (measurement disabled if not
Dimension Tool Measurement
