Gocator 2300 & 2880 Series
Gocator Web Interface • Measurement • 202
Measurement Illustration
Volume
Measures volume in XYZ space.
Area
Measures area in the XY plane.
Thickness
Measures thickness (height) of a part.
Measurements
Parameter Description
Location
(Thickness measurement only)
One of the following:maximum height, minimum
height, average height, median height, the height at
the 2D centroid in the XY plane, or the height at the 3D
centroid in XYZ space.
Decision See Decisions on page 139.
Region See Regions on page 139.
Output See Filters on page 141.
Parameters
Script
A Script measurement can be used to program a custom measurement using a simplified C-based
syntax. A script measurement can produce multiple measurement values and decisions for the output.
See Adding and Removing Tools on page 134 for instructions on how to add measurement tools.
See Script Measurement on the next page for more information on scripts.
