Gocator 2300 & 2880 Series
Gocator Device Files • Job Files • 244
Devices / Device
Element Type Description
@role 32s
Sensor role:
0 – Main
1 – Buddy
DataSource 32s
Data source of device output (read-only):
0 – Top
1 – Bottom
2 – Top Left
3 – Top Right
XSpacingCount 32u Number of resampled points along X (read-only).
YSpacingCount 32u Number of resampled points along Y (read-only).
ActiveArea
Region3D
Active area. (Contains min and max attributes for each element.)
TransformedDataRegion
Region3D
Active area after transformation (read-only).
PatternSequenceType 32s
G3 projection sequence for video mode.
0 – Normal
100 – Nine Lines
PatternSequenceType.optio
ns
32s (CSV) List of available projection sequences.
PatternSequenceType.used Bool Whether or not the type can be selected.
PatternSequenceCount 32u Number of frames in the active sequence (read-only)..
FrontCamera
Window
Front camera window (read-only).
BackCamera
Window
Back camera window (read-only).
BackCamera.used Bool Whether or not this field is used.
ExposureMode 32s
Exposure mode:
0 – Single exposure
1 – Multiple exposures
2 – Dynamic exposure
ExposureMode.options 32s (CSV) List of available exposure modes.
Exposure 64f Single exposure (µs).
Exposure.min 64f Minimum exposure (µs).
Exposure.max 64f Maximum exposure (µs).
DynamicExposureMin 64f Dynamic exposure range minimum (µs).
DynamicExposureMax 64f Dynamic exposure range maximum (µs).
ExposureSteps 64f (CSV) Mutiple exposure list (µs).
ExposureSteps.countMin 32u Minimum number of exposure steps.
Devices / Device Child Elements
