Gocator 2300 & 2880 Series
Gocator Device Files • Job Files • 245
Element Type Description
ExposureSteps.countMax 32u Maximum number of exposure steps.
IntensityStepIndex 32u Index of exposure step to use for intensity when using multiple
exposures.
XSubsampling 32u Subsampling factor in X.
XSubsampling.options 32u (CSV) List of available subsampling factors in X.
ZSubsampling 32u Subsampling factor in Z.
ZSubsampling.options 32u (CSV) List of available subsampling factors in Z.
SpacingInterval 64f Uniform spacing interval (mm).
SpacingInterval.min 64f Minimum spacing interval (mm).
SpacingInterval.max 64f Maximum spacing interval (mm).
SpacingInterval.used Bool Whether or not field is used.
SpacingInterval value 64f Actual value used.
SpacingIntervalType 32s
Spacing interval type:
0 – Maximum resolution
1 – Balanced
2 – Maximum speed
3 – Custom
SpacingIntervalType.used Bool Whether or not field is used.
Tracking Section
See Tracking on the next page.
Material Section
See Material on the next page.
Custom Custom Used by specialized sensors.
Element Type Description
X 64f X start(mm).
Y 64f Y start (mm).
Z 64f Z start (mm).
Width 64f X extent (mm).
Length 64f Y extent (mm).
Height 64f Z extent (mm).
Region3D Child Elements
Element Type Description
X 32u X start (pixels).
Y 32u Y start (pixels).
Width 32u X extent (pixels).
Height 32u Y extent (pixels).
Window Child Elements
