LMI Technologies Gocator 2300 Series User Manual

Gocator 2300 & 2880 Series
Gocator Device Files • Job Files • 255
Element Type Description
6 – Z Min
7 – Z Max
8 – Median
RegionEnabled Boolean Setting to enable/disable region:
0 – Disable
1 – Enable
Region
Region3D
Element for feature detection volume.
SurfaceRegion2d
An element of type SurfaceRegion2d defines a rectangular area of interest on the X-Y plane.
Element Type Description
X 64f Setting for surface region X position (mm).
Y 64f Setting for surface region Y position (mm).
Width 64f Setting for region width (mm).
Length 64f Setting for region length (mm).
SurfaceRegion2d Child Elements
ProfileArea
A ProfileArea element defines settings for a profile area tool and one or more of its measurements.
Element Type Description
Name String Tool name.
Source 32s Profile source.
Anchor\X String (CSV) The X measurements (IDs) used for anchoring.
Anchor\X.options String (CSV) The X measurements (IDs) available for anchoring.
Anchor\Z String (CSV) The Z measurements (IDs) used for anchoring.
Anchor\Z.options String (CSV) The Z measurements (IDs) available for anchoring.
Type Boolean
Area to measure:
0 – Object (convex shape above the baseline)
1 – Clearance (concave shape below the baseline)
Type.used Boolean Whether or not field is used.
Baseline Boolean
Baseline type:
0 – X-axis
1 – Line
Baseline.used Boolean Whether or not field is used.
Region
ProfileRegion2d
Measurement region.
Line
ProfileLine
Line definition when Baseline is set to Line.
ProfileArea Child Elements
