LMI Technologies Gocator 2300 Series User Manual

Gocator 2300 & 2880 Series
Gocator Device Files • Job Files • 259
Element Type Description
1 – Enable
SmoothingEnabled Boolean
Smoothing enable state:
0 – Disable
1 – Enable
SmoothingWindow 32u Smoothing window.
Scale 64f Output scaling factor.
Offset 64f Output offset factor.
DecisionMin 64f Minimum decision threshold.
DecisionMax 64f Maximum decision threshold.
ProfileCircle
A ProfileCircle element defines settings for a profile circle tool and one or more of its measurements.
Element Type Description
Name String Tool name.
Source 32s Profile source.
Anchor\X String (CSV) The X measurements (IDs) used for anchoring.
Anchor\X.options String (CSV) The X measurements (IDs) available for anchoring.
Anchor\Z String (CSV) The Z measurements (IDs) used for anchoring.
Anchor\Z.options String (CSV) The Z measurements (IDs) available for anchoring.
Region
ProfileRegion2d
Measurement region.
Measurements\X Circle tool
measurement
X measurement.
Measurements\Z Circle tool
measurement
Z measurement.
Measurements\Radius Circle tool
measurement
Radius measurement.
ProfileCircle Child Elements
Element Type Description
@id 32s Measurement ID. Optional (measurement disabled if not
set).
Name String Measurement name.
Enabled Boolean
Measurement enable state:
0 – Disable
1 – Enable
Circle Tool Measurement
