Gocator 2300 & 2880 Series
Specifications • Gocator 2300 Series • 385
Gocator 2300 Series
The Gocator 2300 series consists of the sensor models defined below.
MODEL 2320 2330 2340 2342 2350 2370 2375 2380
Data Points /
Profile
1280 1280 1280 1280 1280 1280 1280 1280
Linearity Z
(+/- % of MR)
0.01 0.01 0.01 0.01 0.01 0.04 0.05 0.04
Resolution Z (mm) 0.0018 -
0.0030
0.006 -
0.014
0.013 -
0.037
0.015 -
0.040
0.019 -
0.060
0.055 -
0.200
0.154 - 0.56 0.092-
0.488
Resolution X (mm)
(Profile Data
Interval)
0.014 - 0.021 0.044 -
0.075
0.095 -
0.170
0.095 -
0.170
0.150 -
0.300
0.275 -
0.550
0.27 - 0.80 0.375 -
1.100
Repeatability Z
(µm)
0.4 0.8 1.2 1.2 2 8 N/A 12
Clearance
Distance (CD)
(mm)
40 90 190 190 300 400 650 350
Measurement
Range (MR) (mm)
25 80 210 210 400 500 1350 800
Field of View (FOV)
(mm)
18 - 26 47 - 85 96 - 194 64 - 140 158 - 365 308 - 687 345 - 1028 390 - 1260
Recommended
Laser Class
2M 2M 3R 3R 3R 3B 3B-N 3B
Other Laser
Classes
3R 3R, 3B 3B 3B 3B
Dimensions (mm) 35x120x149.5 49x75x142 49x75x197 49x75x197 49x75x272 49x75x272 49x75x272 49x75x272
Weight (kg) 0.8 0.74 0.94 0.94 1.3 1.3 1.3 1.3
Optical models, laser classes, and packages can be customized. Contact LMI for more details.
Specifications stated are based on standard laser classes. Linearity Z, Resolution Z, and Repeatability Z
may vary for other laser classes.
All specification measurements are performed on LMI’s standard calibration target (a diffuse, painted
white surface).
Linearity Z is the worst case difference in average height measured, compared to the actual position over
the measurement range.
Resolution Z is the maximum variability of height measurements across multiple frames, with 95%
confidence.
Resolution X is the distance between data points along the laser line.
