Gocator 2300 & 2880 Series
Specifications • Gocator 2300 Series • 386
Repeatability Z is measured with a flat target at the middle of the measurement range. It is the 95%
confidence variation of the average height over 4096 frames. Height values are averaged over the full
FOV.
See Resolution and Accuracy on page 43 for more information.
ALL 2300 SERIES MODELS
Scan Rate
Approx. 170Hz to 5000 Hz
Interface Gigabit Ethernet
Inputs Differential Encoder, Laser Safety Enable, Trigger
Outputs 2x Digital output, RS-485 Serial (115 kBaud), 1x Analog Output (4 - 20 mA)
Input Voltage (Power) +24 to +48 VDC (13 Watts); RIPPLE +/- 10%
Housing Gasketed aluminum enclosure, IP67
Operating Temp. 0 to 50° C
Storage Temp. -30 to 70° C
Mechanical dimensions for each sensor model are illustrated on the following pages.
