Gocator 2300 & 2880 Series
Gocator Device Files • Job Files • 247
Element Type Description
CameraGainAnalog 64f Analog camera gain factor.
CameraGainAnalog.used Bool Determines if the setting’s value is currently used.
CameraGainAnalog.value 64f Value in use by the sensor, useful for determining value when used is
false.
CameraGainAnalog.min 64f Minimum value.
CameraGainAnalog.max 64f Maximum value.
CameraGainDigital 64f Digital camera gain factor.
CameraGainDigital.used Bool Determines if the setting’s value is currently used.
CameraGainDigital.value 64f Value in use by the sensor, useful for determining value when used is
false.
CameraGainDigital.min 64f Minimum value.
CameraGainDigital.max 64f Maximum value.
DynamicSensitivity 64f Dynamic exposure control sensitivity factor. This can be used to scale the
control setpoint.
DynamicSensitivity.used Bool Determines if the setting’s value is currently used.
DynamicSensitivity.value 64f Value in use by the sensor, useful for determining value when used is
false.
DynamicSensitivity.min 64f Minimum value.
DynamicSensitivity.max 64f Maximum value.
DynamicThreshold 32s Dynamic exposure control threshold. If the detected number of spots is
fewer than this number, the exposure will be increased.
DynamicThreshold.used Bool Determines if the setting’s value is currently used.
DynamicThreshold.value 32s Value in use by the sensor, useful for determining value when used is
false.
DynamicThreshold.min 32s Minimum value.
DynamicThreshold.max 32s Maximum value.
GammaType 32s Gamma type.
GammaType used Bool Value in use by the sensor, useful for determining value when used is
false.
GammaType value 32s Determines if the setting’s value is currently used.
SurfaceGeneration
The SurfaceGeneration element contains settings related to surface generation.
Element Type Description
Type 32s
Surface generation type:
0 – Continuous
1 – Fixed length
2 – Variable length
SurfaceGeneration Child Elements
