Gocator Device Files • Job Files • 243
Element Type Description
StationaryTarget 32s
Stationary alignment target:
0 – None
1 – Disk
2 – Bar
3 – Plate
StationaryTarget.options 32s (CSV) List of available stationary alignment targets.
MovingTarget 32s
Moving alignment target:
0 – None
1 – Disk
2 – Bar
3 – Plate
MovingTarget.options 32s (CSV) List of available moving alignment targets.
EncoderCalibrateEnabled Bool Enables encoder resolution calibration.
Disk Section
See Disk below.
Bar Section
See Bar below.
Plate Section
See Plate below.
Disk
Element Type Description
Diameter 64f Disk diameter (mm).
Height 64f Disk height (mm).
Disk Child Elements
Bar
Element Type Description
Width 64f Bar width (mm).
Height 64f Bar height (mm).
HoleCount 32u Number of holes.
HoleDistance 64f Distance between holes (mm).
HoleDiameter 64f Diameter of holes (mm).
Bar Child Elements
Plate
Element Type Description
Height 64f Plate height (mm).
HoleCount 32u Number of holes.
RefHoleDiameter 64f Diameter of reference hole (mm).
SecHoleDiameter 64f Diameter of secondary hole(s) (mm).
Plate Child Elements
