Gocator 2300 & 2880 Series
Protocols • Gocator Protocol • 334
Field Type Offset Description
exposure 32u 25 Exposure (ns).
reserved[3] 8u 29 Reserved.
points[C][W] 8u 32 Intensity arrays.
Surface
Field Type Offset Description
size 32u 0 Count of bytes in message (including this field).
control 16u 4 Bit 15: Last message flag.
Bits 0-14: Message type identifier. For this message, set to 8.
attributeSize 16u 6 Size of attributes, in bytes (min: 40, current: 40).
length (L) 32u 8 Surface length (rows).
length (W) 32u 12 Surface width (columns).
xScale 32u 16 X scale (nm).
yScale 32u 20 Y scale (nm).
zScale 32u 24 Z scale (nm).
xOffset 32s 28 X offset (µm).
yOffset 32s 32 Y offset (µm).
zOffset 32s 36 Z offset (µm).
source 8u 40 Source
0 – Top
1 – Bottom
2 – Top Left
3 – Top Right
exposure 32u 41 Exposure (ns).
rotation 32s 45 Rotation(microdegrees).
reserved[3] 8u 49 Reserved.
ranges[L][W] 16s 52 Surface ranges.
Surface Intensity
Field Type Offset Description
size 32u 0 Count of bytes in message (including this field).
control 16u 4 Bit 15: Last message flag.
Bits 0-14: Message type identifier. For this message, set to 9.
attributeSize 16u 6 Size of attributes, in bytes (min: 32, current: 32).
length (L) 32u 8 Surface length (rows).
