Gocator 2300 & 2880 Series
Protocols • Gocator Protocol • 302
Field Type Offset Description
id 16u 4 Reply identifier (0x4002).
status 32s 6
Reply status. For a list of status codes, see Commands on page
295.
localInfo
Sensor
Info
10 Info for this device.
remoteCount 32u 66 Number of discovered sensors.
remoteInfo
[remoteCount]
Sensor
Info
70 List of info for discovered sensors.
Field Type Offset Description
deviceId 32u 0 Serial number of the device.
address[4] byte 4 IP address (most significant byte first).
modelName[32] char 8 Model name.
firmwareVersion[4] byte 40 Firmware version (most significant byte first).
state 32s 44
Sensor state
-1 – Conflict
0 – Ready
1 – Running
For more information on states, see Control Commands on page
299.
role 32s 48
Sensor role
0 – Main
1 – Buddy
buddyId 32s 52 Serial number of paired device (main or buddy). 0 if unpaired.
Sensor Info
Get States
The Get States command returns various system states.
Field Type Offset Description
length 32u 0 Command size including this field, in bytes.
id 16u 4 Command identifier (0x4525)
Command
Field Type Offset Description
length 32u 0 Reply size including this field, in bytes.
id 16u 4 Reply identifier (0x4525).
status 32s 6
Reply status. For a list of status codes, see Commands on page
295.
Reply
