Gocator 2300 & 2880 Series
47
Gocator Web Interface
The following sections describe the Gocator web interface.
User Interface Overview
Gocator sensors are configured by connecting to a Main sensor with a web browser. The Gocator web
interface is illustrated below.
Element Description
1 Manage page Contains settings for sensor system layout, network, motion and
alignment, handling jobs, and sensor maintenance. See System
Management and Maintenance on page 56.
2 Scan page Contains settings for scan mode, trigger source, detailed sensor
configuration, and performing alignment. See Scan Setup and
Alignment on page 73.
3 Model page Lets you set up part matching. See Models and Part Matching on
page 118
To Next Page
