Gocator 2300 & 2880 Series
Gocator Device Files • Job Files • 252
BoundingBox
Element Type Description
ZAngle 64f Z rotation to apply to bounding box (degrees).
Acceptance/Width/Min 64f Minimum width (mm).
Acceptance/Width/Max 64f Maximum width (mm).
Acceptance/Length/Min 64f Minimum length (mm).
Acceptance/Length/Max 64f Maximum length (mm).
BoundingBox Child Elements
Ellipse
Element Type Description
ZAngle 64f Z rotation to apply to ellipse (degrees).
Acceptance/Major/Min 64f Minimum major length (mm).
Acceptance/Major/Max 64f Maximum major length (mm).
Acceptance/Minor/Min 64f Minimum minor length (mm).
Acceptance/Minor/Max 64f Maximum minor length (mm).
Ellipse Child Elements
ToolOptions
The ToolOptions element contains a list of available tool types, their measurements, and settings for
related information.
Element Type Description
<Tool Names> Collection Acollection of tool name elements. An element for each
tool type is present.
ToolOptions Child Elements
Element Type Description
@displayName String Display name of the tool.
@isCustom Bool Reserved for future use.
MeasurementOptions Collection
See MeasurementOptions below
Tool Name Child Elements
MeasurementOptions
Element Type Description
<Measurement Names> Collection Acollection of measurement name elements. An element
for each measurement is present.
MeasurementOptions Child Elements
