Gocator 2300 & 2880 Series
Protocols • Gocator Protocol • 325
Field Type Offset Description
length 32u 0 Command size including this field, in bytes.
id 16u 4 Command identifier (0x4531).
toolIndex 32u 6 Index of the tool instance the new measurement is added to.
typeName[64] char 10 Type name of the measurement (for example, X).
name[64] char 74 User-specified name of the measurement instance.
Command
Field Type Offset Description
length 32u 0 Reply size including this field, in bytes.
id 16u 4 Reply identifier (0x4531).
status 32s 6
Reply status. For a list of status codes, see Commands on page
295.
Reply
Only some tools allow the addition of new measurements. The maximum number of instances
for a given measurement type can be found under MeasurementOptions in the ToolOptions
node. For dynamic tools, the maximim, indicated by the maxCount attribute, is greater than one.
For static tools, the maximum is one.
Read File (Progressive)
The progressive Read File command reads the content of a file as a stream.
This command returns an initial reply, followed by a series of "continue"replies if the initial reply's status
field indicates success. The continue replies contain the actual data, and have 0x5000 as their identifier.
Field Type Offset Description
length 32u 0 Command size including this field, in bytes.
id 16u 4 Command identifier (0x4529).
name[64] char 6 Source file name.
Command
Field Type Offset Description
length 32u 0 Reply size including this field, in bytes.
id 16u 4 Reply identifier (0x4529).
status 32s 6
Reply status. For a list of status codes, see Commands on page
295.
progressTotal 32u 10 Progress indicating completion (100%).
progress 32u 14 Current progress.
Initial Reply
